S5B T0

The S5B T0 is preconfigured with:

CPU - 2 x Gold 6230 20c
RAM - 16 x (up to 24) 32GB 2933Mhz
NVMe - 12 x U.2 15.6TB
NIC - 2 x Dual 100G Mellanox
OS SSD - 2 x 256GB SATADOM
Rack Rails + peripherals
optional - DC Persistent Memory 12 * 512GB DIMM

  • $USD $85,634.00

    *RRP Pricing*

    To View Channel Discounts Please Login


S5B T0

S5B Tier 0 Storage Server The S5B series is the industry's first 12 x U.2 ALL Flash NVMe storage server and to this day still offers a 20% storage capacity advantage per 1RU over its nearest peer. The S5B T0 is

S5B Tier 0 Storage Server

The S5B series is the industry's first 12 x U.2 ALL Flash NVMe storage server and to this day still offers a 20% storage capacity advantage per 1RU over its nearest peer.


The S5B T0 is pre-configured to meet the high end: Compute, storage and network demands of Tier 0 workloads such as:

  • Machine Learning
  • FPGA cards
  • Artificial Intelligence AI
  • Deep Learning
  • Trading; and
  • Big Data




Pre-Configured for Tier 0 workloads


Server Market Comparison: HS Vs HPE Vs Dell Vs CISCO

When we put the S5B T0 up against: ProLiant DL360 (HPE) PowerEdge R640 (Dell) C220 M5 (CISCO) here's what we found. The S5B T0 offers:

  •  A 20% storage capacity advantage per 1RU over its nearest peer;
  •  A min of 50% cost saving to its nearest peer
  •  Free of software lock ins
  •  Free of hardware lock ins



Configure your own S5B TC Configurable

Configure your own S5B TC with choice of CPU, RAM, HDD, SSD, NVMe, here

Qualified Operating Systems

Technology partners





Processor

Processor Type

Intel®Xeon® Processor Scalable Family (refer to the CCL)

Max. TDP Support

165W

Number of Processors

2 Processors

Internal Interconnect

9.6/10.4 GT/s

Form Factor

Form Factor

1U

Dimensions

W x H x D (inch)

17.3 x 1.7 x 30.7

W x H x D (mm)

440 x 43.2 x 780

Chipset

Chipset

Intel® C621

Intel® C624

Storage

Default Configuration

NVMe support

2.5" Hot-plug

3.5" Hot-plug

SKU - #1

[All Flash SKU]:

(12) 2.5" hot-plug SATA/ NVMe SSD

SKU - #2

[SFF Tiered SKU]:

(8) 2.5" hot-plug SATA/SAS drives + (4) 2.5" hot-plug NVMe/SATA/SAS drives

SKU - #3

[Hybrid SKU]:

Option 1
(4) 3.5"/2.5" hot-plug SATA/SAS drives, (4) 9mm NVMe/SATA/SAS drives (optional)

Option 2
(4) 3.5"/2.5" hot-plug SATA/SAS drives, (4) 9mm SATA/SAS drives (optional)

Memory

Total Slots

24

Capacity

Up to 3TB (128Gx24) of memory for RDIMM/LRDIMM

Memory Type

2666 MHz DDR4 RDIMM

Memory Size

64GB, 32GB, 16GB, 8GB RDIMM

(Refer to CCL)

Expansion Slot

SKU - #1

[All Flash SKU]


(1) PCIe Gen3 x16 OCP 2.0 mezzanine slot or PHY card
(1) PCIe Gen3 x16 LP MD-2
(1) PCIe Gen3 x8 FHHL

SKU - #2

Option 1 (3PCIe)
(1) PCIe Gen3 x16 SAS mezzanine slot
(1) PCIe Gen3 x16 OCP 2.0 mezzanine slot or PHY card
(1) PCIe Gen3 x16 LP MD-2
(2) PCIe Gen3 x 8 LP MD-2

Option 2 (2PCIe)
(1) PCIe Gen3 x16 SAS mezzanine slot
(1) PCIe Gen3 x16 OCP 2.0 mezzanine slot or PHY card
(1) PCIe Gen3 x 8 FHHL
(1) PCIe Gen3 x16 LP MD-2

SKU - #3

Option 1 (3PCIe)
(1) PCIe Gen3 x16 SAS mezzanine slot
(1) PCIe Gen3 x16 OCP 2.0 mezzanine slot or PHY card
(1) PCIe Gen3 x16 LP MD-2
(2) PCIe Gen3 x 8 LP MD-2

Option 2 (2PCIe)
(1) PCIe Gen3 x16 SAS mezzanine slot
(1) PCIe Gen3 x16 OCP 2.0 mezzanine slot or PHY card
(1) PCIe Gen3 x16 FHHL
(1) PCIe Gen3 x16 LP MD-2

Network Controller

LOM

Dedicated (1) GbE management port

Optional NIC

Quanta Intel® X527 10G SFP+ dual/quad-port OCP PHY mezzanine or
Quanta Intel® X557 10G RJ45 dual/quad-port OCP PHY mezzanine or
Quanta Intel® I357 1G RJ45 dual/quad-port OCP PHY mezzanine or
(more options refer to the CCL)

Front I/O

Front I/O

(2) USB 3.0 ports
Power/ID/Reset Buttons
Power/ID/Status LEDs

Storage Controller

Onboard

Intel® 621/ 624:
14x SATA 6Gb/s ports
SATA RAID 0, 1, 10

Optional Controller

Quanta LSI® 3216 12Gb/s SAS mezzanine
Quanta LSI® 3516 12Gb/s SAS mezzanine (RAID 0,1,5,6,10,50,60)
Intel® VROC Upgrade Module for PCIe SSD

(2) PCIe M.2 support with M.2 adapter for boot optimization (option)

Power Supply

Power Supply

(1+1) High efficiency redundant hot-plug Platinum/Titanium 500W/800W* PSU
(detailed PSU options please refer to "ordering info" or "CCL")

Onboard Storage

Onboard Storage

(2) SATADOM (option)

Fan

Fan

(8) dual rotor fans (15+1 redundant)

Video

Video

Integrated ASPEED AST2500 8MB DDR4 video memory

System Management

System Management

Redfish v1.1
IPMI v2.0 Compliant, on board "KVM over IP" support
QCT System Manager (QSM) v1.8 (Optional)

Rear I/O

Rear I/O

(2) USB 3.0 ports
(1) VGA port
(1) RS232 serial port
(1) GbE RJ45 management port
(1) ID LED
(1) MicroSD slot

Operating Environment

Operating Environment

Operating temperature: 5°C to 40°C (can support 45°C under certain situation)
Non-operating temperature: -40°C to 70°C
Operating relative humidity: 20% to 85%RH
Non-operating relative humidity: 10% to 95%RH

TPM

TPM

TPM 1.2/2.0 SPI module

Weight (Max. Configuration)

Weight (Max. Configuration)

31KG



Datasheet 1
Title Version Date Size
S5B-T0_DS / D52B-1U_DS v20171128 2017/11/28 302 KB
User manual 1
Title Version Date Size
S5B-T0_DS / D52B-1U_UG 1.0 2017/11/20 5.26 MB
Bill of Materials 1
Title Version Date Size
S5B-T0_BoM v1.0 2018/03/31
