System Form Factor        2U Rackmount

Dimension (D x W x H)   32.71" x 17.25" x 3.43" (831 x 438.4 x 87mm)

Gross Weight     33.1 kg (73 lbs)

Net weight          20.3 kg (44.8 lbs)

Front Panel         Buttons (1) UID / (1) PWR w/ LED / (1) RST

LEDs       (1) HDD / (1) UID / (2) LAN / (1) System Event

I/O Ports              (2) USB 3.1 Gen.1 ports

External Drive Bay            Q'ty / Type          (8) 3.5" Hot-swap HDD/SSDs

Front Drive Bay Interface              (8) SATA 6Gb/s / NVMe

Front HDD Backplane Support    SAS 12Gb/s /SATA 6Gb/s /NVMe

Notification        The SAS/SATA HDD backplane is connected to onboard SATA connection by default.

System Cooling Configuration     FAN       (5) 8cm fans

Power Supply    Type      CRPS

Input Range        AC 200-240V/12.6A

Frequency          47-63 Hz

Output Watts     2,200 Watts

Efficiency             PFC / 80 plus Platinum

Redundancy       1+1

Processor            Q'ty / Socket Type           (2) AMD Socket SP3

Supported CPU Series    (2) AMD EPYC™ 7002/7003 Series Processors

Thermal Design Power Wattage Max up to 240W* (cTDP)

#Notification      240W CPUs are supported with certain condition. Please contact Technical Support before purchasing

Memory              Supported DIMM Qty     (8)+(8) DIMM slots

DIMM Type / Speed        DDR4 ECC RDIMM/RDIMM 3DS/LRDIMM/LRDIMM 3DS 3200

Capacity               Up to 2,048GB RDIMM / 4,096GB LRDIMM 3DS

Memory channel              8 Channels per CPU

Memory voltage               1.2V

Expansion Slots Pre-installed Riser Card (PCIe Gen.4)           (1) M8251T83-L32-2F riser card for (2) FH/FL PCIe Gen.4 x16 / (1) M8251T83-R32-2F riser card for (2) FH/FL PCIe Gen.4 x16 / (1) M8251T83-LR32-2L riser card for (1) HH/HL PCIe Gen.4 x16 (right) +(1) HH/HL PCIe Gen.4 x16 (left) slots

Physical Dimension Abbreviation              FH/FL (Full-height / Full-length): 4.4" x 12.3" (111.2 x 312mm)

LAN        Q'ty / Port           (2) 10GbE ports + (1) GbE dedicated for IPMI

Controller            Intel X550-AT2

PHY        Realtek RTL8211E

Storage SATA     Connector           (8) SATA from (2) Slim SAS (8 ports) / (2) SATA-DOM

Controller            Direct from AMD EPYC CPU

Speed   6Gb/s

Storage NVMe  Connector (U.2) (4) SFF-8654 for (8) front NVMe

Graphic Connector type D-Sub 15-pin

Resolution          Up to 1920x1200

Chipset BMC Aspeed AST2500

I/O Ports              USB        (1) USB3.1 Gen.1 port (Type-A) / (2) USB3.1 Gen.1 ports (via Cable) / (2) USB3.1 Gen.1 ports (@ rear)

COM      (1) header ( COM1 )

VGA       (1) D-Sub 15-pin port

RJ-45     (2) 10 GbE ports + (1) dedicated GbE for IPMI

SATA     (2) SATA-DOM connectors / (8) SATA from (2) Slim SAS connectors

TPM (Optional) TPM Support     Please refer to our TPM supported list.

System Monitoring          Chipset Aspeed AST2500

Temperature     Monitors temperature for CPU & memory & system environment

Voltage Monitors voltage for CPU, memory, chipset & power supply

LED         Over temperature warning indicator / Fan & PSU fail LED indicator

Others  Watchdog timer support

Server Management      Onboard Chipset              Onboard Aspeed AST2500

AST2500 iKVM Feature  24-bit high quality video compression / Supports storage over IP and remote platform-flash / USB 2.0 virtual hub

AST2500 IPMI Feature   IPMI 2.0 compliant baseboard management controller (BMC) / 10/100/1000 Mb/s MAC interface

BIOS      Brand / ROM size             AMI / 32MB

Feature Hardware Monitor / FAN speed control automatic / Boot from USB device/PXE via LAN/Storage / Console Redirection / SMBIOS 3.0/PnP/Wake on LAN / ACPI 6.1 / ACPI sleeping states S0, S5

Operating System            OS supported list              Please refer to our AVL support lists.

Regulation          FCC (SDoC)         Class A

CE (DoC)              Class A

CB/LVD Yes

RCM      Class A

VCCI      Class A

Operating Environment Operating Temp.              10° C ~ 35° C (50° F~ 95° F)

Non-operating Temp.    - 40° C ~ 70° C (-40° F ~ 158° F)

In/Non-operating Humidity 90    90%, non-condensing at 35° C

RoHS     RoHS 6/6 Compliant        Yes
